4G Lab: Orchestrator

Installation of Orchestrator with one IP instead of five

Video by Nitin Rajput (click on the above pic to see installation of orchestrator)

First, clone the repo

git clone https://github.com/ShubhamTatvamasi/magma-galaxy

Install Dependant Collections

ansible-galaxy collection install -U shubhamtatvamasi.magma
ansible-galaxy collection list

Setup Ansible (Ubuntu 20.04 LTS Setup):

sudo apt-get remove --purge ansible
sudo apt update
sudo apt install software-properties-common
sudo add-apt-repository --yes --update ppa:ansible/ansible
sudo apt install ansible
ansible-galaxy collection install shubhamtatvamasi.magma --force-with-deps

Copy your public SSH key to the host:

ssh-keygen -R 192.168.5.70
ssh-copy-id ubuntu@192.168.5.70

Update your values in the hosts.yml file before running the playbook.

Change directory to deploy folder.

Deploy Magma orchestrator:

ansible-playbook deploy-orc8r.yml

Note: After deployment is done it takes around 10 minutes to start all the magma services.

Create a new user:

On the orc8r terminal, run these commands.

ORC_POD=$(kubectl get pod -l app.kubernetes.io/component=orchestrator -o jsonpath='{.items[0].metadata.name}')
kubectl exec -it ${ORC_POD} -- envdir /var/opt/magma/envdir /var/opt/magma/bin/accessc \
  add-existing -admin -cert /var/opt/magma/certs/admin_operator.pem admin_operator

NMS_POD=$(kubectl get pod -l app.kubernetes.io/component=magmalte -o jsonpath='{.items[0].metadata.name}')
kubectl exec -it ${NMS_POD} -- yarn setAdminPassword master admin admin
kubectl exec -it ${NMS_POD} -- yarn setAdminPassword magma-test admin admin
